Endress+Hauser Differential pressure Deltabar PMD75

Differential pressure transmitter with metal sensor for measurement of pressure differences

The Deltabar PMD75 differential pressure transmitter with with piezoresistive sensor and welded metallic membrane is used in all industries for continuous measurement in liquids, vapors and gases. The 3-key operation enables simple and reliable commissioning and operation. The integrated HistoROM data module allows easy management of process and device parameters. Designed according to IEC 61508 for use in SIL2/3 safety applications.

Benefits

Best accuracy, reproducibility and long-term stability

Highest safety due to gas tight feedthrough with capabilities up to SIL2/3, certified to IEC 61508

Easy menu-guided commissioning via local display, 4 to 20mA with HART, PROFIBUS PA, FOUNDATION Fieldbus

HistoROM data management concept for fast and easy commissioning, maintenance and diagnostics

Cost savings with modular concept for easy replacement of sensor, display or electronics

Overload-resistant up to 420bar / 42MPa / 6300psi, function-monitored

Seamless and independent system integration (HART/PA/FF)

Field of application

For level, volume or mass measurement in liquids, differential pressure monitoring as well as flow measurement (volume or mass flow) in conjunction with primary elements in gases, vapors and liquids.

Process connections: Threads

Process temperature: -40 to +85°C (-40 to +185°F)

Measuring ranges: 0.25mbar to 40bar (0.0036 to 600psi)

Accuracy: ±0.05%, “Platinum” ±0.025% (optional)

International explosion protection certificates, overfill prevention WHG, SIL, hygienic approvals, marine approvals
